H-Type Rough Terrain Forklift

GZFR80 H | 8 Ton Forklift

Power：
Load Capacity：
Load Center：
Product Size：
Max Lift Height：
Product Weight：
WhatsApp
Message
Email

Product Overview

The GWZOOM GZFR80 H is an 8 ton all terrain fork truck engineered as a 4x4 forklift with heavy duty counterweight technology for ultimate stability. The H-Type series delivers traditional multi-lever control precision combined with a compact turning radius uncommon in this capacity class. This all terrain fork truck handles the heaviest loads across the roughest terrain, making it ideal for mining, heavy construction, and port operations.

Technical Specifications

Key Technical Parameters
Model		GZFR80 H
Rated Load	kg	8000
Load Center Distance	mm	500
Wheelbase	mm	2550
Kingpin Height	mm	670
Minimum Ground Clearance (At the Mast)	mm	260
Track Width (Front/Rear)	mm	1730/1800
Minimum Turning Radius (Outer)	mm	4910
Minimum Turning Radius (Inner)	mm	2530
Front Tire		12.00R24 (Two Wheel)
Rear Tire		12.00R24
Engine		XiChai 4DX22-96
Engine Power	kw	92
Number of Transmission Gears		Front 2/ Rear 2
