H-Type Rough Terrain Forklift

GZFR35 H | 3.5 Ton Forklift

Power：
Load Capacity：
Load Center：
Product Size：
Max Lift Height：
Product Weight：
WhatsApp
Message
Email

Product Overview

The GWZOOM GZFR35 H is a 3.5 ton carton clamp forklift (optional attachment) engineered as a versatile off road forklift with heavy duty counterweight design. The H-Type series combines traditional multi-lever controls with a compact turning radius and heavy duty chassis for unmatched stability. This off road forklift excels in logistics, warehousing, and recycling operations where clamp attachments enhance productivity.

Technical Specifications

Key Technical Parameters
Model		GZFR35 H
Rated Load	kg	3500
Load Center Distance	mm	500
Wheelbase	mm	2050
Kingpin Height	mm	560
Minimum Ground Clearance (At the Mast)	mm	260
Track Width (Front/Rear)	mm	1500
Minimum Turning Radius (Outer)	mm	3150
Minimum Turning Radius (Inner)	mm	1350
Front Tire		20.5/70-16
Rear Tire		20.5/70-16
Engine		Yunnei 490 Turbo
Engine Power	kw	58
Number of Transmission Gears		Front 2/ Rear 2
